Rugged Industrial Monitoring Control Panel Cabinet with Touchscreen Interface

Core Concept
The RCS-9000 Series Monitoring Control Panel Cabinet is an engineered solution for mission-critical industrial environments, integrating visualization, control, and data acquisition in a single NEMA 4X/IP66-rated enclosure. Designed for oil/gas, utilities, and manufacturing applications across Canadian climate zones (-40°C to +55°C operational range).

Availability:

Quantity:



Inquire Add to Basket

Industrial Monitoring Cabinet Control Panel Enclosure NEMA 4X Rated Touchscreen HMI SCADA Integration PLC-Compatible

Product Description

Modular Architecture

Base Frame: Standard 19" rack (42U) with vibration-dampened mounting
Wire Management: Vertical DIN rails + finger-safe cable ducts
Component Layers:

Power distribution tier (surge-protected PDUs)
Controller tier (dual hot-swappable PLC slots)
Visualization tier (swing-arm monitor mount)

Environmental Resilience

Ice load resistance: Withstands 50mm radial ice buildup
Condensation control: Auto-humidistat with moisture ejector
Chemical resistance: NACE MR0175 compliant for H₂S environments

Maintenance Optimization

Tool-less front/rear access with 180° hinges
QR-coded component database (scan for schematics)
Lifecycle monitoring of critical parts (fans/batteries)

Certification Highlights

Explosion Safety: IECEx/ATEX certified for Class I Div 2
EMC Compliance: EN 61000-6-2/-4 industrial immunity
Accessibility: ADA-compliant control height

Environmental Resilience
Designed for Canada's extreme climates with triple-sealed conduit entries and polarized air vents:

Parameter	Specification	Test Standard
Temperature Range	-40°C to +55°C (operational)	CSA C22.2 No. 94-17
Ice Load Resistance	50mm radial ice (2" thickness)	IEEE 696
Humidity Control	Auto-dehumidifier (10-95% RH non-condensing)	UL 50E
Chemical Resistance	H₂S ≤ 20ppm, pH 3-11 exposure	NACE MR0175/ISO 15156
Wind Load Rating	160 km/h (Cat.3 Hurricane)	ASCE/SEI 7-22

Electrical & Safety Compliance

Feature	Configuration	Certification
Enclosure Rating	NEMA 4X / IP66	CSA C22.2 No. 94
Input Voltage	Dual 120/240V AC + 24V DC UPS	UL 508A
Hazardous Location	Class I Div 2, Zone 2 AEx d IIC T4	CSA C22.2 No. 30
EMC Shielding	40dB attenuation (10MHz-1GHz)	EN 61000-6-4
Seismic Performance	Zone 4 (0.5g PGA)	IEEE 693-2018
